Model Description | ||
Product Model | Input Voltage | Relay Voltage |
LC-41F-1/12V | 12VDC/AC | 12VDC |
LC-41F-1/24V | 24VDC/AC | 24VDC |
LC-41F-1/48V | 48VDC/AC | 48VDC |
LC-41F-1/60V | 60VDC/AC | 60VDC |
LC-41F-1/110V | 110VAC | 60VDC |
LC-41F-1/220V | 220VAC | 60VDC |
Rated current | 6A |
Rated voltage | 250VAC，30VDC |
Dielectric strength | 4000V/S between coil and contact |
Torque | 0.5Nm |
Suitable for cables | 20~16AWG |
Operating temperature range | -40℃~70℃ |
Power consumption | 0.17W |
Adapt to solid state | LC-N5G |
